Connecting GitHub Actions to AWS with the Access keys.

GitHub Actions workflows are often designed to access a cloud provider (such as AWS, Azure, GCP, or HashiCorp Vault) to deploy software or use the cloud’s services. To access cloud resources, it will supply credentials, such as a password or token, to the cloud provider. These credentials are usually stored as secrets in GitHub, and the workflow presents this secret to the cloud provider every time it runs.

However, using hardcoded secrets requires you to create credentials in the cloud provider and then duplicate them in GitHub as a secret.

In a GitHub Actions workflow connecting to AWS with access keys, the process involves configuring the AWS Command Line Interface (CLI) within the workflow. This is typically done using the aws-actions/configure-aws-credentials GitHub Action. The action requires specifying the AWS Access Key ID and Secret Access Key, which are stored as secrets in the GitHub repository. These secrets are securely retrieved during the workflow execution. Once configured, the AWS CLI can be utilized in subsequent workflow steps to interact with AWS services, enabling tasks such as deploying applications, managing infrastructure, or executing other AWS-related commands. This approach provides a streamlined and secure way for GitHub Actions to communicate with AWS resources using access keys while adhering to best practices for managing sensitive information.

Create an IAM User and Access Keys

1. Goto IAM -> users -> Create user



2. Add the policies required for the user. I am adding limited permissions to users with AmazonS3ReadOnlyAccess.



3. On the Review and Create page: review the user details and permissions. Add the Tags Name: GitHub-Actions(optional).



4. we can see the github user is created successfully/Click on the github user



5. Click on the Create access key option.



6. Select the access keys use case as Command Line Interface (CLI). Click on Next.



7. The set description tag is optional. Click on the Create access key.



8. The access key is created. download the .csv file and copy those keys.



Create a GitHub Repository

1. Create a repository to perform Github Actions.



2. After creating the repository click on the code -> codespaces -> Create codespace on main.



3. It will create a codespace and open the Visual Studio code workspace with the repository files.



4. Click on the settings and then select Secrets and Variables.



5. Select the Actions and then click on the New Repository Secret.



6. Add the AWS_ACCESS_KEY to the secrets



7. Add the AWS_SECRETS_ACCESS_KEY to the secrets



8. we can view the list of secrets which are configured in the repository.



9. Create a basic workflow file, such as github-aws-credentials.yml, Add the .github/workflows directory to your repository. This sample workflow will connect to the AWS. Your repository can have multiple workflows, each performing different sets of tasks. After GitHub is authenticated with the AWS credentials in the workflow, you can use AWS CLI commands in your account.

10. Paste the following example workflow into the file.

    # This is a basic workflow to help you get started with Actions
    name: Connect to an AWS from a GitHub repository with AWS Credentials
    # Controls when the action will run. Invokes the workflow on push events but only for the main branch
    on:
      push:
        branches: [ main ]
      pull_request:
        branches: [ main ]
    env:
      AWS_REGION : <"us-east-1"> #Change to reflect your Region
    jobs:
      AWSConnect:
        runs-on: ubuntu-latest
        steps:
          - name: Git clone the repository
            uses: actions/checkout@v3
          - name: Configure AWS Credentials
            uses: aws-actions/configure-aws-credentials@v4
            with:
              aws-access-key-id: ${{ secrets.AWS_ACCESS_KEY }}
              aws-secret-access-key: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
              aws-region: ${{ env.AWS_REGION }}
          - name: List the S3 buckets
            run: aws s3 ls


11. Modify the workflow to reflect your AWS account information:

    • AWS_REGION: Enter the AWS Region for your AWS resources.

12. Push the workflow file to the repository.



13. Whenever we push the code to the repository, It will automatically triggers the workflow file.



14. The figure shows the workflow steps in which GitHub does the following:

    • The action configures the AWS Command Line Interface (CLI) with the provided AWS Access Key ID, AWS Secret Access Key, and AWS region.

    • Once configured, the AWS CLI can be used in subsequent steps of the GitHub Actions workflow to interact with AWS resources. This can include tasks such as deploying applications, managing infrastructure, or performing other AWS-related operations.

    • The use of ${{ secrets.AWS_ACCESS_KEY_ID }} and ${{ secrets.AWS_SECRET_ACCESS_KEY }} ensures that sensitive information (AWS credentials) is securely retrieved from GitHub repository secrets. This is a best practice to protect sensitive data in a GitHub Actions workflow.

    • The specified AWS region (your-aws-region) is where the subsequent AWS CLI commands will be executed. It's essential to replace your-aws-region with the actual AWS region you want to target.

    • This action is a crucial step in AWS-related workflows, as it sets up the necessary credentials for GitHub Actions to interact with AWS services securely. It enables the seamless integration of AWS commands within the workflow, allowing for automated deployments, infrastructure management, and other AWS tasks as defined in the workflow.

By following these steps, you establish a secure connection between your GitHub Actions workflow and your AWS account, allowing you to perform AWS-related tasks as part of your automated workflow. It's crucial to use secrets for sensitive information to prevent exposing access keys directly in your code.

Remember to keep your credentials secure and avoid hardcoding them directly in your workflow files. Using GitHub secrets provides a more secure way to manage sensitive information.

Certainly! While the traditional approach of using access keys for authentication has been widely employed, there are compelling reasons to consider moving towards OpenID Connect (OIDC).

Conclusion

In conclusion, the shift from the normal approach of using access keys to OIDC is driven by a desire for improved security, user-centricity, compliance, scalability, and ease of integration. Embracing OIDC represents a strategic move towards a more modern, standardized, and robust authentication and authorization framework in the evolving landscape of web services.

---
